BSW 350 II

Stage light

Precise optical system to make gobo/color showing sharply, clearly, not any reflected light around gobos/colors;

Silent fans, very small noise only DB 20% of the normal fan noises;

Module designs for easy assembling and warranty;

Special designed IC making cool and running long time;

Power supply: 100-240 V AC, 50/60 Hz ~

Power consumption: 500W

Light source: 17R 350W discharge lamp

Frost field angle 8°

Beam angle 2.5°

Zooming from 2.5° to 42°

13 dichroic colors plus open

14 static gobos plus open

9 rotation interchangeable gobos plus open

6-facet prism lens plus 16-facet prism lens

DMX-512-connection: 3-pin XLR

DMX channel: 24/20

Pan/tilt auto repositioning

16 scanning fine bit

Movement:Pan:X axis 530 degrees, Y axis 280 degrees

Flash-rate: 0-30Hz

Dimensions: 480*480*590mm

Weight (net): 21.0kgs

Maximum ambient temperature ta : 40° C
